Speed Pro 351W ci SB Ford - Flat Top Hypereutectic Pistons (SPH336CP 030)

SPH336CP 030 - FORD 351W F/TOP PISTONS HYPER

357 c.i., 4.030" bore, 3.500 stroke, 5.980" rod length, -12.0cc dome volume With 9.5 Deck

Part Number: SPH336CP 030

These ruggedly durable pistons are made with exclusive high strength FM425 alloy, and enhanced with 16.5% silicon for excellent tensile strength and scuff resistance. This advanced metallurgy permits tighter bore clearances, which help minimise noise on cold engine start-up. These pistons are the ideal choice for street performance applications and late-model replacement.

More Sealed Power hypereutectics benefits:
Higher strength than cast or forged at operating temperature

Finely dispersed silicon particles provide a highly resistant wear surface and reduces scuffing
Lower material growth allows pistons to be fit tighter, improving cylinder sealing for less blow-by and more power
High silicon content allows elimination of groove inserts in certain applications
Designed to retain standard ring gaps in the top groove

Piston Specifications :
CID: 357
Bore: 4.030

Stroke: 3.500
Rod Length: 5.980
Compression Height: 1.772

Compression Ratio with 60cc chamber volume: 9.14

Compression Ratio with 63cc chamber volume: 8.91

Compression Ratio with 69cc chamber volume: 8.43

Dome Volume: -12.0cc

Pin Type: Press
Recommended Ring Set: Moly - SPE251K 030, STD Fit - SPR9903 030, File Fit - SPR9343 035
