Scott Drake | SKU:
339-2AL
Scott Drake 2 Row Hi Po Aluminum Radiator - 339-2AL
1967-1969 Ford Mustang, Late Model 5.0, 302 & 351C 2 Row Hi Po Aluminum Radiator
Sold out
Regular price
$892.70 NZD
+ GST
Unit price
/
Unavailable
Shipping calculated at checkout.
Scott Drake 2 Row Hi Po Aluminum Radiator - 339-2AL is not in stock at Fast Lane Spares and will ship direct from supplier
Stock Status:
Description
Description
1967-1969 Ford Mustang, Late Model 5.0, 302 & 351C 2 Row Hi Po Aluminum Radiator
Part Number: 339-2AL
This brand-new, 2-row 20-inch radiator is made from high-quality aluminum. It features 2 rows of extra-large, 1-inch tubes for 4-row efficiency minus the added weight, weighing in at 5-7 fewer pounds. The original, stock radiators for 1967-1969 Mustangs had trouble distributing the hot water to the far-right side of the radiator. This radiator, however, is equipped with Scott Drake's specially designed, extensively tested baffle, which works to dispense the flow of hot water throughout the radiator evenly. This radiator includes a transmission cooler. Its inlet diameter measures 1-1/2 inches and its outlet diameter measures 1-3/4 inches.
Features and Benefits
ā¢ Designed for 1967-1969 Mustang with a late model 5.0L, 302 or 351C engine swap
ā¢ 2 rows of extra-large, 1-inch tubes for 4-row efficiency
ā¢ Made from high quality aluminum
ā¢ Includes a transmission cooler
This radiator is for a late model 5.0L, 302, or 351C engine that has been swapped into a 1967-1969 Mustang. The radiator inlet and outlet are in the correct position to fit a late model engine.
Part Number: 339-2AL
This brand-new, 2-row 20-inch radiator is made from high-quality aluminum. It features 2 rows of extra-large, 1-inch tubes for 4-row efficiency minus the added weight, weighing in at 5-7 fewer pounds. The original, stock radiators for 1967-1969 Mustangs had trouble distributing the hot water to the far-right side of the radiator. This radiator, however, is equipped with Scott Drake's specially designed, extensively tested baffle, which works to dispense the flow of hot water throughout the radiator evenly. This radiator includes a transmission cooler. Its inlet diameter measures 1-1/2 inches and its outlet diameter measures 1-3/4 inches.
Features and Benefits
ā¢ Designed for 1967-1969 Mustang with a late model 5.0L, 302 or 351C engine swap
ā¢ 2 rows of extra-large, 1-inch tubes for 4-row efficiency
ā¢ Made from high quality aluminum
ā¢ Includes a transmission cooler
This radiator is for a late model 5.0L, 302, or 351C engine that has been swapped into a 1967-1969 Mustang. The radiator inlet and outlet are in the correct position to fit a late model engine.
Specifications
Specifications
-
Specifications
Brand Scott Drake Category Belts and Cooling Core Height 16.375 Core Row Quantity 2 Core Width 20.250 Down Flow Or Cross Flow Type Down Flow Emission Code 6 Fan Included No Finish Natural Hose Location Inlet Passenger Hose Location Outlet Driver Inlet Diameter 1 1/2 Inlet Location Passenger Material Aluminum Mounting Type Bracket Mount Outlet Diameter 1-3/4 in. Outlet Location Driver Outlet Size 1-3/4 in. part type Radiator Product Type Radiator Radiator Cap Included No Row Quantity 2 ROWS 2 Sub Category Radiators, Coolers and Related Components Transcooler Provision Yes Transmission Oil Cooler Included Yes Warning California Proposition 65
