Painless 21 Circuit Universal Boot Mount Harness Kit (PW10220)

Our remote boot mount harness provides additional wire from the fuse block to the dash and from the fuse block to the front end, allowing the remote installation of the fuse blockin the boot or behind the rearseat. This 28 Circuit kit allows you to add accessories to the basic wiring such as power windows, door locks, etc. Like all Painless kits this fuse block comes completely pre-wired and terminated for a simple installation. Includes GM column mounted ignition and turn signal switch plugs and terminals.

Number of Circuits: 21 Circuits - 18 Fuses w/ HornRelay & Maxi Fuse
Harness Length: Extra Long Universal
Fuse Type: Blade & Maxi Fuse
Firewall Passthrough: MultipleGrommet
Color Code Based: Universal
CircuitDesignations: Printedon Wires
Connectors Included: GM Column Mounted Ignition and Turn Switches, Dimmer Switch and Two Headlight Pigtails

This harness includes circuits for:

• A/C & Heat
• Accessory
• Accessory / CigaretteLighter
• Accessory / Trunk Light
• Backup Lights
• Brake Lights
• Charging
• Cruise Control
• Dome Light
• Electric Choke
• Electric Fuel Pump
• Emergency Flashers
• Fan Relay Activation Power
• Fused Power Source
• Headlights
• Horn (Relay)
• Ignition Coil
• Instrument Panel Lighting and Gauges*
• Park Lights
• Power Antenna
• Power Door Locks
• Power Windows
• Radio/Clock (Constant and Switched)*
• Starting
• Tail Lights
• Third Brake Light
• Turn Signals
• Wipers

* Including Wires For:

• Fuel Gauge
• Oil Gauge
• Speakers
• Tachometer
• Temperature Gauge
• Voltmeter
