Holley | SKU:
12-893
Holley 12-893 Billet EFI Return Style Fuel Pressure Regulator
EFI Return Style Regulator 59.5 PSI Black Finish
Regular price
$460.70 NZD
+ GST
Unit price
/
Unavailable
Shipping calculated at checkout.
Holley 12-893 Billet EFI Return Style Fuel Pressure Regulator is not in stock at Fast Lane Spares and will ship direct from supplier
⚠ Special Order Item — ships direct from supplier. No returns, exchanges, or cancellations once processed. Please allow 7–20 days shipping.
Stock Status:
Holley 12-893 Billet EFI Return Style Fuel Pressure Regulator
Regular price
$460.70 NZD
+ GST
Unit price
/
Unavailable
Description
Description
EFI Return Style Regulator 59.5 PSI Black Finish
Part Number: 12-893
The billet EFI fuel pressure regulator is designed to be a space saving option when mounting on the end of the fuel rail or near the throttle body. The fuel pressure regulator is preset at 59.5 psi. The regulator cap can be removed and re-oriented to suit desired fuel routing. The billet 6061-T6 body has been machined for SAE6 ports and has three 6AN fittings and one extra plug included. An all black or black/clearcoat anodized finish is available. These fuel pressure regulators are compatible with Holley Sniper or Sniper Stealth among other applications. Regulator is suitable up to 110 GPH pump flowrate. In terms of pump models that would be a 525lph pump or smaller.
Features and Benefits
• Constructed from Billet 6061-T6 Aluminum
• Anodized in all black or black and clear
• Machined for all SAE6 ports, with 3 6AN fittings included
• Includes an extra plug to replace one fitting when installed post throttle body / fuel rail
• Can be disassembled and re-oriented to suit desired fuel routing
• Pre-set 59.5 psi
• Compatible with Holley Sniper and Sniper Stealth among other applications
• Regulator is suitable up to 110 GPH pump flowrate. In terms of pump models that would be a 525lph pump or smaller.
Part Number: 12-893
The billet EFI fuel pressure regulator is designed to be a space saving option when mounting on the end of the fuel rail or near the throttle body. The fuel pressure regulator is preset at 59.5 psi. The regulator cap can be removed and re-oriented to suit desired fuel routing. The billet 6061-T6 body has been machined for SAE6 ports and has three 6AN fittings and one extra plug included. An all black or black/clearcoat anodized finish is available. These fuel pressure regulators are compatible with Holley Sniper or Sniper Stealth among other applications. Regulator is suitable up to 110 GPH pump flowrate. In terms of pump models that would be a 525lph pump or smaller.
Features and Benefits
• Constructed from Billet 6061-T6 Aluminum
• Anodized in all black or black and clear
• Machined for all SAE6 ports, with 3 6AN fittings included
• Includes an extra plug to replace one fitting when installed post throttle body / fuel rail
• Can be disassembled and re-oriented to suit desired fuel routing
• Pre-set 59.5 psi
• Compatible with Holley Sniper and Sniper Stealth among other applications
• Regulator is suitable up to 110 GPH pump flowrate. In terms of pump models that would be a 525lph pump or smaller.
Specifications
Specifications
-
Specifications
Adjustable No Application Universal Brand Holley Category Air and Fuel Delivery Color Black Emission Code 5 Fuel System EFI Fuel Type Gasoline Gauge Port No Grade Type Performance Inlet Quantity 1 Inlet Size 6 AN Inlet Type 6 AN Material Billet 6061 Aluminum Mounting Hardware Included No Mounting Type Inline Outlet Quantity 1 Outlet Size 6 AN Outlet Type 6 AN part type Fuel Pressure Regulator Port Quantity 3 Pressure Range 59.5 Pre-Set Product Type Fuel Pressure Regulator Return Size 6 AN Style Return Style Sub Category Carburetion Warning California Proposition 65 Warranty Manufacturer's Limited 90 Day Warranty -
