Blueprint SB Ford 347 c.i.d Crate Engine, Dressed (PSEBP3474CTC)

NOTE: Pictures of Crate Engines are for reference only, engine componenets & accessories are subject to change by manufacture without notice based on availability of parts at time of assembly.

BLOCK:

• Hand picked seasoned block
• Square and parallel decked
• Align honed main bearing bore
• Cylinders honed on computer controlled machine to within .0002 straightness and roundness
• Cylinders are sonic tested for thickness
• 2-Bolt Main
• 4.000" Bored .040" Over
• 1-Piece Rear Main Seal
• Mech fuel pump provision: Yes

ROTATING ASSEMBLY:

• New BluePrint Cast steel crankshaft
• 3.400" Stroke
• Forged I-beam 5.400" connecting rods
• Forged pistons
• 28oz External balance

CYLINDER HEADS:

• BluePrint Aluminum Cylinder Heads -HP9008
• 60cc chamber
• 2.02" intake/1.60" exhaust valves
• 190cc intake/65cc exhaust runners

CAM SPECS:

• Cam Type: Roller
• .543 Intake .554 Exhaust
• 218 Intake / 226 Exhaust duration
• @ .050 - 112 degree lobe separation

IGNITION TIMING:

• 34 Degrees Total at 3500 RPM

ALSO INCLUDES:

• Dual plane, satin aluminum intake manifold
• 600cfm carburetor
• Distributor
• Valve covers
• Painted oil pan
• Brass freeze plugs
• Dyno test results shipped with engine

NOTES:

• Not for use in pollution controlled vehicles.
• Engine timing cover is designed for standard rotation water pump ONLY
