Pulsar Turbo Systems | SKU: PULSAR1871

Pulsar PSR PRO98 HP Rating 2550

$4,779.00 NZD + GST

Shipping calculated at checkout.

Compressor Housing Options

Standard T51R MOD

Turbine Housing Options

1.09A/R Dual V-Band 1.25 A/R Dual V-Band 1.41 A/R Dual V-Band T6 Open 1.25A/R T6 Open 1.41A/R

Product variants

Pulsar PSR PRO98 HP Rating 2550 - Standard / 1.09A/R Dual V-Band is not in stock at Fast Lane Spares and will ship direct from supplier

This item may not be kept in physical stock, in some instances item will be shipped direct from supplier.

Please contact us prior to purchasing if you would like an accurate ETA.

Description

Dual ceramic ball bearing system provides optimal turbo response &
better durability by reducing the shaft-motion
13 Blade G-Aero billet compressor wheel 98mm inducer produces up to 2550 hp
9 Blade G-Aero Inconel 713c turbine wheel with more turbine flow
Fin cooled aluminum center housing, lighter weight
Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
Installation Hardware: 4” flange kit for Comp. Outlet, T6 Gasket/3.5” flange kit for Turb. Inlet, 5” flange kit for Turb. Outlet and oil Drain Fitting kit are included by default
Oil Feed Fitting needs to be bought separately check the link if you need it, 🔗

Compressor Wheel: 98.4*133.5*142.4mm
Turbine Wheel: 118*112mm
Compressor Inlet: 6” Hose
Compressor Outlet: 4” V-band
Compressor Housing A/R: 0.96
Turbine Inlet: 3.5” V-Band (DV Housings) or T6 Open
Turbine Outlet: 5” V-Band
Turbine Housing A/R: 1.09/1.25/1.41
Oil Feed: See graph below (OIL INLET) (an oil restrictor with ~1mm orifice is highly recommended)
Oil Drain: See graph below (OIL OUTLET)
