Speed Pro 400 ci SB Chev - Flat Top Hypereutectic Pistons (SPH616CP 030) SPH616CP 030

Speed Pro 400 ci SB Chev - Flat Top Hypereutectic Pistons (SPH616CP 030)

400 c.i., 4.155" bore, 3.750 stroke, 5.700" rod length, -6.0cc dome volume
SKU: SPH616CP 030
$533.90 - $533.90
$533.90
$533.90 - $533.90
$533.90
+ GST
Stock Status: ⚠️ Low stock — contact before purchasing

SBC 400 CHEV FLAT TOP PISTONS

400 c.i., 4.155" bore, 3.750 stroke, 5.700" rod length, -6.0cc dome volume

Part Number: SPH616CP 030

Available on both hypereutectic and POWERFORGED pistons, DUROSHIELD is an exclusive moly-graphite skirt
coating that extends engine life and essentially eliminates scuffing. This technologically advanced coating is precisely applied to the piston through a computer-controlled process.

DUROSHIELD skirt coated pistons:

  • Reduce friction for increased fuel economy and horsepower
  • Essentially eliminate scuffing and wear
  • Prevent damage from inadequate lubrication, especially at start-up
  • Improve cylinder sealing for less blow-by and more power
  • Require no increase in skirt clearance

Piston Specifications :

  • CID: 407
  • Bore: 4.155
  • Stroke: 3.750
  • Rod Length: 5.700
  • Compression Height: 1.425
  • Compression Ratio with 64cc chamber volume: 10.84
  • Compression Ratio with 72cc chamber volume: 9.99
  • Compression Ratio with 76cc chamber volume: 9.62
  • Dome Volume: -6.0cc
  • Pin Type: Press
  • Recommended Ring Set: Moly - SPE243K 030, STD Fit - SPR10374 030, File Fit - SPR5879 035
  • Coated skirt
