Speed Pro 460 ci BB Ford - Flat Top Hypereutectic Pistons (SPH535CP 060) SPH535CP 060

Speed Pro 460 ci BB Ford - Flat Top Hypereutectic Pistons (SPH535CP 060)

473 c.i., 4.420" bore, 3.850 stroke, 6.700" rod length, -4.2cc dome volume
SKU: SPH535CP 060
$533.10 - $533.10
$533.10
$533.10 - $533.10
$533.10
+ GST
Stock Status: ⚠️ Low stock — contact before purchasing

FORD 460 PISTONS +60 FLAT TOP

473 c.i., 4.420" bore, 3.850 stroke, 6.700" rod length, -4.2cc dome volume

Part Number: SPH535CP 060

Available on both hypereutectic and POWERFORGED pistons, DUROSHIELD is an exclusive moly-graphite skirt
coating that extends engine life and essentially eliminates scuffing. This technologically advanced coating is precisely applied to the piston through a computer-controlled process.

DUROSHIELD skirt coated pistons:

  • Reduce friction for increased fuel economy and horsepower
  • Essentially eliminate scuffing and wear
  • Prevent damage from inadequate lubrication, especially at start-up
  • Improve cylinder sealing for less blow-by and more power
  • Require no increase in skirt clearance

Piston Specifications :

  • CID: 473
  • Bore: 4.420
  • Stroke: 3.850
  • Rod Length: 6.700
  • Compression Height: 1.752
  • Compression Ratio with 72cc chamber volume: 10.93
  • Compression Ratio with 77cc chamber volume: 10.45
  • Compression Ratio with 97cc chamber volume: 8.91
  • Dome Volume: -4.2cc
  • Pin Type: Press
  • Recommended Ring Set: Moly - SPE296K 060, STD Fit - N/A, File Fit - SPR10246 065
  • Coated skirt
