Speed Pro 460 ci BB Ford - Flat Top Hypereutectic Pistons (SPH535CP 030) SPH535CP 030

Speed Pro 460 ci BB Ford - Flat Top Hypereutectic Pistons (SPH535CP 030)

466 c.i., 4.390" bore, 3.850 stroke, 6.700" rod length, -4.2cc dome volume
SKU: SPH535CP 030
$513.90 - $513.90
$513.90
$513.90 - $513.90
$513.90
+ GST
Stock Status: ⚠️ Low stock — contact before purchasing

FORD 460 PISTONS +30 FLAT TOP

466 c.i., 4.390" bore, 3.850 stroke, 6.700" rod length, -4.2cc dome volume

Part Number: SPH535CP 030

Available on both hypereutectic and POWERFORGED pistons, DUROSHIELD is an exclusive moly-graphite skirt
coating that extends engine life and essentially eliminates scuffing. This technologically advanced coating is precisely applied to the piston through a computer-controlled process.

DUROSHIELD skirt coated pistons:

  • Reduce friction for increased fuel economy and horsepower
  • Essentially eliminate scuffing and wear
  • Prevent damage from inadequate lubrication, especially at start-up
  • Improve cylinder sealing for less blow-by and more power
  • Require no increase in skirt clearance

Piston Specifications :

  • CID: 466
  • Bore: 4.390
  • Stroke: 3.850
  • Rod Length: 6.700
  • Compression Height: 1.752
  • Compression Ratio with 72cc chamber volume: 10.81
  • Compression Ratio with 77cc chamber volume: 10.33
  • Compression Ratio with 97cc chamber volume: 8.81
  • Dome Volume: -4.2cc
  • Pin Type: Press
  • Recommended Ring Set: Moly - SPE296K 030, STD Fit - N/A, File Fit - SPR10246 035
  • Coated skirt
