Speed Pro 454 ci BB Chev - Dome Top Hypereutectic Pistons (SPH693CP 030) SPH693CP 030

Speed Pro 454 ci BB Chev - Dome Top Hypereutectic Pistons (SPH693CP 030)

461 c.i., 4.280" bore, 4.000 stroke, 6.135" rod length, +22.0cc dome volume
SKU: SPH693CP 030
$563.60 - $563.60
$563.60
$563.60 - $563.60
$563.60
+ GST
Stock Status: ⌛ Available — ships from supplier, allow 2–10 days shipping

CHEV 454 DOME TOP PISTONS

461 c.i., 4.280" bore, 4.000 stroke, 6.135" rod length, +22.0cc dome volume

Part Number: SPH693CP 030

Available on both hypereutectic and POWERFORGED pistons, DUROSHIELD is an exclusive moly-graphite skirt
coating that extends engine life and essentially eliminates scuffing. This technologically advanced coating is precisely applied to the piston through a computer-controlled process.

DUROSHIELD skirt coated pistons:

  • Reduce friction for increased fuel economy and horsepower
  • Essentially eliminate scuffing and wear
  • Prevent damage from inadequate lubrication, especially at start-up
  • Improve cylinder sealing for less blow-by and more power
  • Require no increase in skirt clearance

Piston Specifications :

  • CID: 461
  • Bore: 4.280
  • Stroke: 4.000
  • Rod Length: 6.135
  • Compression Height: 1.640
  • Compression Ratio with 100cc chamber volume: 10.91
  • Compression Ratio with 117cc chamber volume: 9.48
  • Compression Ratio with 124cc chamber volume: 8.97
  • Dome Volume: +22.0cc
  • Pin Type: Press or float
  • Recommended Ring Set: Moly - SPE233K 030, STD Fit - SPR9905 030, File Fit - SPR9590 035
  • Coated skirt
