Meziere True Billet 164 Tooth SFI Flexplate, 8-Bolt. .18" Thick (MZFP346)

MZFP346 - FLEXPLATE FORD MODULAR 8 BOLT

Suit Ford Modular V8

Part Number: MZFP346

These plates are clearly the superior choice for quality and precision. Machined to exacting tolerances from 4340 round bar, our proprietary manufacturing process ensures the strongest gear tooth, least runout, and the best longevity on the market. All of our flexplates are certified to SFI 29.2.

Concentric machined to .005"
One piece design - 100% machined

Proprietary heat treating process
Chamfered gear tooth provides better engagement
Fits Ford Modular 4.6 and 5.8 with 8 bolt crankshaft
164 tooth ring gear
12 pitch tooth profile
Weighs 7.3 pounds
Converter pattern 1 - 4 holes 7/16" diameter on 10.50" bolt circle

Converter pattern 2 - 4 holes 7/16" diameter on 11.38" bol circle

Converter pattern 3 - 3 holes 7/16" diameter on 10.75" bolt circle

Converter pattern4 - 3 holes 7/16" diameter on 11.5" bolt circle
